Opti-motion

Performance
• Synchronization slides for smooth &
silent operation. Perfect undermount slides
perform excellent sliding action for
wooden drawer systems serve
the needs of tod ay’s cabinetry’s de mand.

• Length : 250mm - 600mm

• Travel : Single & Full Extension
• Maximum Material Thickness : 16mm

• Load capacity of 30kgs

• Undermounted / Concealed

• Easy Removal / Fitting with front locking device
+ /-1.5mm side adjustment & +3.0mm height adjustment
• Intergrated Impul for a silent & soft closing motion
