               Cabinet Member Fixing Positions


                                                         Minimum internal cabinet depth = drawer length + 3mm
                                                                                                 Drawer Length

                                                                                                   350mm

                         Front edge of cabinet
                              5mm set back
                                                                                                   400mm
                                     18
                               9  19        19
                                                                                                   450mm
                                              9

                                                                                                   500mm

                                        28
                                       37                                                          550mm
                                                                               32           3
                                                                          32  64  32  128  37


               Front Installation Dimensions






                                                                              For press-in and expansion
                                                                              front fixing brackets to
                                                      + 1.0                   pre-drill ø10mm x12mm
                                                    35.5 - 1.0       35.5

                                                min. 47
                                                          93                32
                                                min.58                      52



                                                       Bottom panel width + 30mm





                Cutting Dimensions for 16mm Chipboard             Back Installation Dimensions


                    Back Panel
                    Width   = Internal cabinet width - 81mm
                    Height  = 84mm
                    Bottom Panel
                    Width = Internal cabinet width - 71mm                                  9
                    Length (Wooden back)  = Drawer length - 24mm
                                                                             20
                                                                            32










                                                                                                                7
