Page 56 - Q-Fit Catalogue and Technical Manual

®

Cabinet Member Fixing Positions

Minimum internal cabinet depth = drawer length + 3mm
Drawer Length

350mm

Front edge of cabinet
5mm set back
400mm
18
9 19 19
450mm
9

500mm

28
37 550mm
32 3
32 64 32 128 37

Front Installation Dimensions

For Expansion
Railing to
pre-drill
+ 1.0 ø10mm x 12mm
35.5 - 1.0 35.5
For press-in
and expansion
front fixing
brackets to
pre-drill
ø10mm x 12mm
min. 110 64
32
93
min.58 52

Bottom panel width + 30mm

Cutting Dimensions for 16mm Chipboard Back Installation Dimensions

Back Panel
Width = Internal cabinet width - 81mm
Height = 142mm
9
Bottom Panel 14
Width = Internal cabinet width - 71mm
Length (Wooden back) = Drawer length - 24mm 32
32
32

9
