Page 58 - Q-Fit Catalogue and Technical Manual
P. 58

®







               Cabinet Member Fixing Positions


                                                         Minimum internal cabinet depth = drawer length + 3mm
                                                                                                Drawer Length

                                                                                                   350mm

                         Front edge of cabinet
                              5mm set back
                                                                                                   400mm
                                     18
                               9  19        19
                                                                                                   450mm
                                              9

                                                                                                   500mm

                                        28
                                       37                                                          550mm
                                                                               32           3
                                                                         32  64  32  128  37


               Front Installation Dimensions

                                                                              For Expansion
                                                      + 1.0                   Railing to
                                                    35.5  - 1.0       35.5    pre-drill
                                                                              ø10mm x 12mm


                                                                            64
                                                                              For press-in
                                                min. 180                      front fixing
                                                                              and expansion
                                                                              brackets to
                                                                            64  pre-drill
                                                                              ø10mm x 12mm
                                                                            32
                                                          93
                                                min.58                      52




                                                       Bottom panel width + 30mm


               Cutting Dimensions for 16mm Chipboard             Back Installation Dimensions

                 Back Panel
                 Width   = Internal cabinet width - 81mm                                   9
                 Height  = 206mm                                            14
                                                                            32
                 Bottom Panel
                 Width = Internal cabinet width - 71mm
                 Length (Wooden back)  = Drawer length - 24mm               32
                                                                            32
                                                                            32
                                                                            32







                                                                                                                11
