Page 110 - Q-Fit Catalogue and Technical Manual

®

Front installation dimensions

+ _ 1.5
15.5 +1.5 15.5 15.5 1.0 15.5 15.5 +1.5 15.5
_ 1.0
_ 1.0
min. 56 8.5 min. 56 17.5 min. 56 17.5
86 18
min. 58 49 min. 90 118 32 81 min. 122 150 64 113

9
9
9

H 86 mm - 7030/7031 H 118 mm - 7230/7231 H 150 mm - 7430/7431

Back installation dimensions

9 9 9

32 32 32
34.5 32 32

34.5 32
34.5

H 86 mm - 7030/7031 H 118 mm - 7230/7231 H 150 mm - 7430/7431

Plug-In drilling dimension Cutting dimensions for 16mm chipboard
for bottom panel
Bottom Panel Back Panel
Width = Internal cabinet width - 31mm Width = Internal cabinet width - 31mm
Length (Wooden back) = Drawer length - 18mm Height = 7030/7031 = 71mm
Length (Steel back) = Drawer length - 28mm 7230/7231 = 103mm
7430/7431 = 135mm

Pre-drill Ø5mm x 10mm deep

32
69
9 9
Front Panel
Width = Internal cabinet width - 64mm
Height = 7030/7031 = 61mm
7230/7231 = 93mm
7430/7431 = 125mm
Note: Min. internal cabinet depth = drawer length + 15mm
25
