P. 60

®







               Cabinet Member Fixing Positions


                                                         Minimum internal cabinet depth = drawer length + 3mm
                                                                                                Drawer Length

                                                                                                   350mm

                         Front edge of cabinet
                              5mm set back
                                                                                                   400mm
                                     18
                               9  19        19
                                                                                                   450mm
                                              9

                                                                                                   500mm

                                        28
                                       37                                                          550mm
                                                                              32            3
                                                                         32  64  32  128  37


               Front Installation Dimensions






                                                      + 1.0                   For press-in and expansion
                                                    35.5 - 1.0       35.5
                                                                              front fixing brackets to
                                                                              pre-drill ø10mm x12mm
                                               min77
                                                         123                32

                                               min.58                       52



                                                      Bottom panel width + 30mm





               Cutting Dimensions for 16mm Chipboard             Back Installation Dimensions

                 Back Panel
                 Width   = Internal cabinet width - 81mm
                 Height  = 114mm
                 Bottom Panel
                 Width = Internal cabinet width - 71mm                                     9
                 Length (Wooden back)  = Drawer length - 24mm
                                                                            20
                                                                            32
                                                                            32








                                                                                                               13
