Page 70 - Q-Fit Catalogue and Technical Manual

®
OptiBox BIF38 Double Wall Side Extension Internal Drawer

Cabinet Profile Drawer Side
1 2
Left / Right Left / Right
4 Drawer Length
350mm OB48.35RH/LH OD38.35RH/LH
400mm OB48.40RH/LH OD38.40RH/LH
5
450mm OB48.45RH/LH OD38.45RH/LH
500mm OB48.50RH/LH OD38.50RH/LH
550mm OB48.55RH/LH OD38.55RH/LH
6
3 Cover Cap

9
2 Left QPC.350LH
Right QPC.350RH
3
8 1
7
4 Rear Fixing Bracket Left / Right (for wooden back)
Left QRB.280LH
• Full Extension with concealed roller guided runners
Right QRB.280RH
• Steel drawer side 82mm
• Load capacity of 40 kgs 5 Railing set (x2 pcs)
• Equipped with fast assembly system
350mm QRAS.321.BP
• 2-dimensional front adjustment
400mm QRAS.371.BP
• Intergrated Impul for a silent & soft closing motion 450mm QRAS.421.BP
• Applicable to wooden front panel & 500mm QRAS.471.BP
internal front fixing bracket 550mm QRAS.521.BP

Double Railing
7 6 Boxside Left / Right
Front Fixing Bracket Left / Right
Left QFB.330LH Drawer Length
Screw On Right QFB.330RH 450mm Left QBSS.450LH
Right QBSS.450RH
Internal Front
8 9 Cross Railing 500mm Left QBSS.500LH
Profile
Right QBSS.500RH
Cabinet Width
550mm Left QBSS.550LH
1000mm QFP.1000L QCR.1000L
Right QBSS.550RH
(Front profile to be cutting in size)
Colour R9010 White • R9006 Grey Metalic • R9017 Black R9010 White • R9006 Grey Metallic • R9017 Black
Colour
