Page 67 - Q-Fit Catalogue and Technical Manual

®
OptiBox GD38 Glass Side Extension Standard Drawer

Cabinet Profile Drawer Side
1 2
Left / Right Left / Right
Drawer Length
350mm OB48.35RH/LH OD38.35RH/LH

4 400mm OB48.40RH/LH OD38.40RH/LH
450mm OB48.45RH/LH OD38.45RH/LH
5
500mm OB48.50RH/LH OD38.50RH/LH
550mm OB48.55RH/LH OD38.55RH/LH
6
3 Cover Cap

7 Left QPC.350LH
1
2 Right QPC.350RH
3

4 Rear Fixing Bracket Left / Right (for wooden back)
• Full Extension with concealed roller guided runners Left QRB.280LH
• Steel drawer side 82mm Right QRB.280RH
• Load capacity of 40 kgs
5 Railing set (x2 pcs)
• Equipped with fast assembly system
• 2-dimensional front adjustment 350mm QRAS.321.BP
400mm QRAS.371.BP
• Intergrated Impul for a silent & soft closing motion
450mm QRAS.421.BP
500mm QRAS.471.BP
550mm QRAS.521.BP

7 Front Fixing Bracket Left / Right 6 Tempered Glass Left / Right

Screw On QFB.210 x2 pcs ! 3.5 x 15.0mm Drawer Length
Press in QFB.220 x2 pcs ! 10.5 x 11.5mm 350mm QGS310LH/RH
Expansion QFB.230 x2 pcs ! 10.0 x 11.5mm 400mm QGS360LH/RH
450mm QGS410LH/RH
500mm QGS460LH/RH
550mm QGS510LH/RH

Colour
Colour R9010 White • R9006 Grey Metalic • R9017 Black R9010 White • R9006 Grey Metallic • R9017 Black
