Page 68 - Q-Fit Catalogue and Technical Manual

®

Cabinet Member Fixing Positions

Minimum internal cabinet depth = drawer length + 3mm
Drawer Length

350mm

Front edge of cabinet
5mm set back
400mm
18
9 19 19
450mm
9

500mm

28
37 550mm
32 3
32 64 32 128 37

Front Installation Dimensions Cutting dimensions for 4mm tempered glass

min.180 128
Tempered
Glass
+0 -1
32 97 +0 -1
min.58 52 4 -0.5 NL-40
+0.5

Bottom panel width + 30mm

Cutting Dimensions for 16mm Chipboard Back Installation Dimensions

Back Panel
Width = Internal cabinet width - 81mm 9
Height = 206mm
14
32
Bottom Panel
Width = Internal cabinet width - 71mm
Length (Wooden back) = Drawer length - 24mm 32
32
32
32

21
