Page 66 - Q-Fit Catalogue and Technical Manual

®

Cabinet Member Fixing Positions

Minimum internal cabinet depth = drawer length + 3mm
Drawer Length

350mm

Front edge of cabinet
14mm set back
400mm
18
9 19
450mm
9

500mm

28
37 550mm
32
32 64 32 128 37

Front Installation Dimensions Back Installation Dimensions

Internal cabinet width-80mm

9
14
32
64.0
min. 180 32
32
64.0
32
32.0 32
min.58 52.0

Internal cabinet width-90mm
Bottom panel width + 30mm

Cutting Dimensions for 16mm Chipboard Cutting Dimensions For Front Profile

Back Panel
Width = Internal cabinet width - 81mm
Height = 206mm
Bottom Panel
Width = Internal cabinet width - 71mm
Length (Wooden back) = Drawer length - 24mm ICW - 90mm

19
