Page 91 - Q-Fit Catalogue and Technical Manual

InnoBox 6030 / 6031 Drawer Series

3 Steel Back

2 Drawer
Sides L & R
• Single Extension 4
• Metal drawer side height 86 mm Front Brackets
• Epoxy coated
• Load capacity of 30 kgs 5 1 Cabinet Member CR & CL

• Self closing feature Cover Cap
• Flexible 2-dimensional front adjustment
• Side clearance 31mm
• Double out stop safety feature
• Locked-in position when extended

6031 Plug-In

Article no. for
1 Cabinet Member CR & CL
2 Drawer Sides L & R 3 Steel Back
Colors : R9001 Cream • R9010 White • R7004 Grey • R9006 Grey Metallic Colors : R9001 Cream • R9010 White • R7004 Grey • R9006 Grey Metallic
Drawer Length Screw-On Plug-In Cabinet Width Standard
(16mm Side Panel)
270mm 6030.27 6031.27
350mm QMB.03.286
350mm 6030.35 6031.35 400mm QMB.03.336
400mm 6030.40 6031.40 450mm QMB.03.386

450mm 6030.45 6031.45 500mm QMB.03.436
500mm 6030.50 6031.50 550mm QMB.03.486

550mm 6030.55 6031.55 600mm QMB.03.536
700mm QMB.03.636

800mm QMB.03.736

4 Standard Front Brackets 5 Standard Cover Cap
Colors : R9001 Cream • R9010 White • R7004 Grey
Screw- on QFB.110RH
ø3.5 x 15mm (CBS) QFB.110LH QPC.160
Press-in QFB.120RH
ø10.5 x 11.5mm QFB.120LH
Expansion QFB.130RH
ø10 x 11.5mm QFB.130LH
Nickel-plated steel

6
