Page 92 - Q-Fit Catalogue and Technical Manual

®

Cabinet member fixing positions Drilling pattern for cabinet member

Drawer Min.internal Loss of
Length cabinet depth extension
For Ø3.5mm chipboard
270mm 273mm 85mm screws with 7mm dia.head
12.5
350mm 353mm 85mm 2

400mm 403mm 85mm 13

450mm 453mm 95mm
500mm 503mm 102mm front edge of cabinet 9 For Ø4mm chipboard screws
or standard Euro screws
550mm 553mm 110mm 37 with 8mm dia.head
9 9 9 9 9 9 9 9 9 9 2
32 32 32 32 32 32 32 32 32 64 128 37

Front installation dimensions Back installation dimensions

+ 1.5
15.5 _ 1.0 15.5
min. 24 For press-in-front
fixing brackets
to pre-drill
ø10mm X 12mm 9

min. 86 86 64 81 32

8.5 34.5

8.5 Front overlay
Bottom panel width + 14mm

Plug-In drilling dimension for bottom panel Cutting dimensions for 16mm chipboard

Back Panel
Width = Internal cabinet width - 31mm
Height = 71mm

Pre-drill Ø5mm x 10mm deep

32
69
9 9

Bottom Panel
Width = Internal cabinet width - 31mm
Length (Wooden back) = Drawer length - 2mm
Length (Steel back) = Drawer length - 12mm
7
