Page 96 - Q-Fit Catalogue and Technical Manual

®

Drilling pattern for cabinet member
Cabinet member fixing positions
Cabinet member fixing positions Drilling pattern for cabinet member

Drawer Min.internal Loss of For Ø3.5mm chipboard
Length cabinet depth extension screws with 7mm dia.head
12.5
350mm 353mm 85mm 2

400mm 403mm 85mm 13
front edge of cabinet 9 For Ø4mm chipboard screws
450mm 453mm 95mm
500mm 503mm 102mm or standard Euro screws

550mm 553mm 110mm 37 with 8mm dia.head
9 9 9 9 9 9 9 9 9 9 2
32 32 32 32 32 32 32 32 32 64 128 37

Front installation dimensions Back installation dimensions
Front installation dimensions
Back installation dimensions
+ 1.5 15.5
15.5 _ 1.0
For press-in-front
min. 24 fixing brackets 9
to pre-drill
ø10mm X 12mm

32
64
min. 150 150 145 32

72.5 32
34.5

8.5 Front overlay
Bottom panel width + 14mm

Plug-In drilling dimension for bottom panel Cutting dimensions for 16mm chipboard
Cutting dimensions for 16mm chipboard
Plug-In drilling dimension for bottom panel
Back Panel
Width = Internal cabinet width - 31mm
Height = 135mm

Pre-drill Ø5mm x 10mm deep

32
69
9 9

Bottom Panel
Width = Internal cabinet width - 31mm
Length (Wooden back) = Drawer length - 2mm
Length (Steel back) = Drawer length - 12mm
11
