Page 94 - Q-Fit Catalogue and Technical Manual

®

Cabinet member fixing positions Drilling pattern for cabinet member

Drawer Min.internal Loss of For Ø3.5mm chipboard
Length cabinet depth extension screws with 7mm dia.head
12.5
350mm 353mm 85mm 2

400mm 403mm 85mm 13
front edge of cabinet 9 For Ø4mm chipboard screws
450mm 453mm 95mm
500mm 503mm 102mm or standard Euro screws

550mm 553mm 110mm 37 with 8mm dia.head
9 9 9 9 9 9 9 9 9 9 2
32 32 32 32 32 32 32 32 32 64 128 37

Front installation dimensions Back installation dimensions

+ 1.5 15.5
15.5 _ 1.0
min. 24 For press-in-front 9
fixing brackets
to pre-drill
ø10mm X 12mm

64 32
min. 118 118 113 32

40.5 34.5

8.5 Front overlay
Bottom panel width + 14mm

Plug-In drilling dimension for bottom panel Cutting dimensions for 16mm chipboard

Back Panel
Width = Internal cabinet width - 31mm
Height = 103mm

Pre-drill Ø5mm x 10mm deep

32
69
9 9

Bottom Panel
Width = Internal cabinet width - 31mm
Length (Wooden back) = Drawer length - 2mm
Length (Steel back) = Drawer length - 12mm
9
