InnoBox 6230 / 6231 Drawer Series

3 Steel Back

2 Drawer
Sides L & R
• Single Extension
• Metal drawer side height 118 mm
4 Front Brackets
• Epoxy coated
1 Cabinet Member CR & CL
• Load capacity of 30 kgs
• Self closing feature 5
• Flexible 2-dimensional front adjustment Cover Cap
• Side clearance 31mm
• Double out stop safety feature
• Locked-in position when extended

6231 Plug-In

Article no. for
1 Cabinet Member CR & CL
2 Drawer Sides L & R 3 Steel Back
Colors : R9001 Cream • R9010 White • R7004 Grey • R9006 Grey Metallic Colors : R9001 Cream • R9010 White • R7004 Grey • R9006 Grey Metallic
Drawer Length Screw-On Plug-In Cabinet Width Standard
(16mm Side Panel)
350mm 6230.35 6231.35
400mm QMB.23.336
400mm 6230.40 6231.40
450mm QMB.23.386
450mm 6230.45 6231.45
500mm QMB.23.436
500mm 6230.50 6231.50
550mm QMB.23.486
550mm 6230.55 6231.55
600mm QMB.23.536
700mm QMB.23.636
800mm QMB.23.736

4 Standard Front Brackets 5 Standard Cover Cap
Colors : R9001 Cream • R9010 White • R7004 Grey
Screw- on QFB.110RH
ø3.5 x 15mm (CBS) QFB.110LH QPC.160
Press-in QFB.120RH
ø10.5 x 11.5mm QFB.120LH
Expansion QFB.130RH
ø10 x 11.5mm QFB.130LH
Nickel-plated steel
