Page 98 - Q-Fit Catalogue and Technical Manual

®

Front Installation Dimensions
Front installation dimensions

For press-in-front fixing brackets to pre-drill For press-in-front fixing brackets to pre-drill For press-in-front fixing brackets to pre-drill
ø10mm x 12mm ø10mm x 12mm ø10mm x 12mm
+ _ 1.5 _ + 1.5
15.5 1.0 15.5 15.5 +1.5 15.5 15.5 1.0 15.5
_ 1.0

min. 80 64 min. 80 64 min. 80 64

min. 86 86 8.5 64 81 min. 118 118 64 113 min. 150 150 64 145

40.5
8.5 Front overlay 72.5
Bottom panel width + 14mm 8.5 Front overlay
Bottom panel width + 14mm
8.5 Front overlay
Bottom panel width + 14mm
H 86 mm - 6030/6031 H 118 mm - 6230/6231 H 150 mm - 6430/6431

Back installation dimensions
Back Installation dimensions

9 9 9

32 32 32
32 151 32 32
183
32 32 32 215
34.5 32 32

34.5 32
34.5

H 86 mm - 6030/6031 H 118 mm - 6230/6231 H 150 mm - 6430/6431

Plug-In drilling dimension for bottom panel Cutting dimensions for 16mm chipboard

Back Panel
Width = Internal cabinet width - 31mm
Height= 6030/6031 = 135mm
6230/6231 = 167mm
6430/6431 = 199mm

Pre-drill Ø5mm x 10mm deep

32
69
9 9

Bottom Panel
Width = Internal cabinet width - 31mm
Length (Wooden back) = Drawer length - 2mm
Length (Steel back) = Drawer length - 12mm
13
