Page 100 - Q-Fit Catalogue and Technical Manual

®

Front installation dimensions

+
_ +1.5
15.5 _ 1.5 1.0 15.5 15.5 1.0 15.5 15.5 + _ 1.5 1.0 15.5
min.24 min.24 min.24

8.5 17.5 17.5
min. 90 86 18 81 min. 122 118 32 113 min. 154 150 64 145

9
9
9

H 86 mm - 6030/6031 H 118 mm - 6230/6231 H 150 mm - 6430/6431

Back installation dimensions

9 9 9

32 32 32
34.5 32 32
34.5 32

34.5

H 86 mm - 6030/6031 H 118 mm - 6230/6231 H 150 mm - 6430/6431

Plug-In drilling dimension Cutting dimensions for 16mm chipboard
for bottom panel Bottom Panel Back Panel
Width = Internal cabinet width - 31mm Width = Internal cabinet width - 31mm
Length (Wooden back) = Drawer length - 18mm Height = 6030/6031 = 71mm
Length (Steel back) = Drawer length - 28mm 6230/6231 = 103mm
6430/6431 = 135mm

Pre-drill Ø5mm x 10mm deep

32
69
9 9
Front Panel
Width = Internal cabinet width - 64mm
Height = 6030/6031 = 61mm
6230/6231 = 93mm
6430/6431 = 125mm
Note: Min. internal cabinet depth = drawer length + 3mm
15
