Cabinet member fixing positions Drilling pattern for cabinet member

For Ø3.5mm chipboard
screws with 7mm dia.head
Drawer Min.internal Over 2
Length cabinet depth extension
(Fully Open)
350mm 365mm 18mm

400mm 415mm 18mm
450mm 465mm 18mm front edge of cabinet 9 For Ø4mm chipboard screws
or standard Euro screws
with 8mm dia.head
500mm 515mm 18mm
550mm 565mm 18mm 37
9 9 9 9 9 9 9 9 9 9 9 9 2
32 32 32 32 32 32 32 32 32 64 128 37

Front installation dimensions Back installation dimensions

+
15.5 _ 1.5 1.0 15.5
For press-in-front
fixing brackets 9
to pre-drill
ø10mm X 12mm
min. 56 32

64 32
118
min. 86 81 34.5
40.5

8.5 Front overlay
Bottom panel width + 14mm

Plug-In drilling dimension for bottom panel Cutting dimensions for 16mm chipboard

Back Panel
Width = Internal cabinet width - 31mm
Height = 103mm

Pre-drill Ø5mm x 10mm deep

32
69
9 9

Bottom Panel
Width = Internal cabinet width - 31mm
Length (Wooden back) = Drawer length - 2mm
Length (Steel back) = Drawer length - 12mm
19
